Description
Application Scenario
Fit for most EV/HEV
Private redisential
Take away with EV
Benefits
Safe, reliable, compact and stylish design
Support switch on with load
Smalll size, light weight and high efficiency
Customizable branding
Specifications
| Model | L30kW-EN-B | L40kW-EN-B |
| Electrical | ||
| Power | 30kW | 40kW |
| Output Current | 100A | 125A |
| Input Voltage | AC380V±15%, 3P+N+PE, AC220V/230V, L+N+PE (optional), 50Hz/60Hz | |
| Output Voltage | DC200~1000V | |
| Full Load Power Factor | >0.99 | |
| THD | ≤5% | |
| Full of Efficiency | >95% at full load | |
| Interface and Control | ||
| Charging Connector Number | 1 | |
| Charging Connector Type | CCS1, CCS2, GBT | |
| HMI | 4.3'' inch display screen | |
| Languages | Chinese/English (other language available on request) | |
| Environment | ||
| Enclosure Rating | IP32 | |
| Operating Temperature | -30℃~50℃ | |
| Recommended Storage | -40℃~70℃ | |
| Altitude | <2000m (over 2000m de-rating power output) | |
| Relative Humidity | 0~95% (no condensation) | |
| General | ||
| Charging Cable | 5m standard (other length is optional) | |
| Installation Mode | Mobile | |
| Dimension (WxDxH) | 280x550x400mm (without handles and wheels) | |
| Cooling Method | Natural cooling | |
| Safety and Regulation | ||
| Detection and Protection | Insulation protection, Short circuit protection, Over/Under voltage protection, Over current protection, Surge protection, Emergency stop protection. | |
| Standard&Certificate | IEC61851, IEC62196, ISO15118/DIN70121 | |
