Description
Safe, reliable, compact and stylish design.
Modular design, easily maintenance.
200~750V super wide output voltage range
Customizable branding
Specifications
| Model | L120kW-BP |
| Electrical | |
| Maximum Output Power | 120kW |
| Input Voltage | AC380±15%V,50/60Hz,3P+N+PE |
| Output Voltage | DC 200~750V |
| Output Current | 5~240A；200A battery side |
| Full Load Power Factor | >0.99 |
| THD | ≤5% |
| Full of Efficiency | >95% at full load |
| Interface and Control | |
| Charging Connector Number | 2 |
| Charging Connector Type | GB/T |
| HMI | 7''high brightness TFT touch screen display |
| RFID | ISO/IEC 14443A/B, ISO/IEC15393 |
| Network Connection | Ethernet,4G, WiFi |
| Languages | Chinese/English (other language available on request) |
| Platform Communication | KSC |
| Environment | |
| Enclosure Rating | IP54 |
| Operating Temperature | -30℃~50℃ |
| Recommended Storage | -40℃~70℃ |
| Altitude | <2000m (over 2000m de-rating power output) |
| Relative Humidity | 0~95% (no condensation) |
| General | |
| Charging Cable | 5m standard (other length is optional) |
| Installation Mode | Fixed Installation |
| Cooling Method | Forced fan cooling |
| Safety and Regulation | |
| Safety Protection | Insulation protection, short circuit protection, over/under voltage protection, over current protection, surge protection, emergency stop protection. |
| Standard | GB／T27930-2015 |
